There are tons of tutorials on Internet that tech you how to use a web framework and how to create Web applications, and many of these cover Flask, first of all the impressive Flask Mega-Tutorial by Miguel Grinberg (thanks Miguel!).

Why another tutorial, then? Recently I started working on a small personal project and decided that it was a good chance to refresh my knowledge of the framework. For this reason I temporarily dropped the clean architecture I often recommend, and started from scratch following some tutorials. My development environment quickly became very messy, and after a while I realised I was very unsatisfied by the global setup.

So, I decided to start from scratch again, this time writing down some requirements I want from my development setup. I also know very well how complicated the deploy of an application in production can be, so I want my setup to be "deploy-friendly" as much as possible. Having seen too many project suffer from legacy setups, and knowing that many times such issues can be avoided with a minimum amount of planning, I thought this might be interesting for other developers as well. I consider this setup by no means better than others, it simply addresses different concerns.

What you will learn

This post contains a step-by-step description of how I set up a real Flask project that I am working on. It's important that you understand that this is just one of many possible setups, and that my choices are both a matter of personal taste and dictated by some goals that I will state in this section. Changing the requirements would clearly result in a change of the structure. The target of the post is then to show that the setup of a project can take into account many things upfront, without leaving them to an undetermined future when it will likely be too late to tackle them properly.

The requirements of my setup are the following:

  • Use the same database engine in production, in development and for tests
  • Run test on an ephemeral database
  • Run in production with no changes other that the static configuration
  • Have a command to initialise databases and manage migrations
  • Have a way to spin up "scenarios" starting from an empty database, to create a sandbox where I can test queries
  • Possible simulate production in the local environment

As for the technologies, I will use Flask, obviously, as the web framework. I will also use Gunicorn as HTTP server (in prodcution) and Postgres for the database part. I won't show here how to create the production infrastructure, but as I work daily with AWS, I will take into account some of its requirements, trying however not to be too committed to a specific solution.

A general advice

Proper setup is an investment for the future. As we do in TDD, where we decide to spend time now (writing tests) to avoid spending tenfold later (to find and correct bugs), setting up a project requires time, and might frustrate the desire of "see things happen". Proper setup is a discipline that requires patience and commitment!

If you are ready to go, join me for this journey towards a great setup of a Flask application.

The golden rule

The golden rule of any proper infrastructural work is: there has to be a single source of information. The configuration of you project shouldn't be scattered among different files or repositories (not considering secrets, that have to be stored securely). The configuration has to be accessible and easy to convert into different formats to accommodate the needs of different tools. For this reason, the configuration should be stored in a static file format like JSON, YAML, INI, or similar, which can be read and processed by different programming languages and tools.

My format of choice for this tutorial is JSON, as it can be read by both Python and Terraform, and is natively used by ECS on AWS.

Step 1 - Requirements and editor

My standard structure for Python requirements uses 3 files: production.txt, development.txt, and testing.txt. They are all stored in the same directory called requirements, and are hierarchically connected.

File: requirements/production.txt

## This file is currently empty

File: requirements/testing.txt

-r production.txt

File: requirements/development.txt

-r testing.txt

There is also a final requirements.txt file that points to the production one.

File: requirements.txt

-r requirements/production.txt

As you can see this allows me to separate the requirements to avoid installing unneeded packages, which greatly speeds up the deploy in production and keeps things as essential as possible. Production contains the minimum requirements needed to run the project, testing adds to those the packages used to test the code, and development adds to the latter the tools needed during development. A minor shortcoming of this setup is that I might not need in development everything I need in production, for example the HTTP server. I don't think this is significantly affecting my local setup, though, and if I have to decide between production and development, I prefer to keep the former lean and tidy.

I have my linters already installed system-wide, but as I'm using black to format the code I have to configure flake8 to accept what I'm doing

File: .flake8

[flake8]
# Recommend matching the black line length (default 88),
# rather than using the flake8 default of 79:
max-line-length = 100
ignore = E231

This is clearly a very personal choice, and you might have different requirements. Take your time to properly configure the editor and the linter(s). Remember that the editor for a programmer is like the violin for the violinist. You need to know it, and to take care of it. So, set it up properly.

At this point I also create my virtual environment and activate it.

Git commit

You can see the changes made in this step through this Git commit or browse the files.

Resources

Step 2 - Flask project boilerplate

As this will be a Flask application the first thing to do is to install Flask itself. That goes in the production requirements, as that is needed at every stage.

File: requirements/production.txt

Flask

Now, install the development requirements with

$ pip install -r requirements/development.txt

As we saw before, that file automatically installs the testing and production requirements as well.

Then we need a directory where to keep all the code that is directly connected with the Flask framework, and where we will start creating the configuration for the application. Create the application directory and the file config.py in it.

File: application/config.py

import os

basedir = os.path.abspath(os.path.dirname(__file__))


class Config(object):
    """Base configuration"""


class ProductionConfig(Config):
    """Production configuration"""


class DevelopmentConfig(Config):
    """Development configuration"""


class TestingConfig(Config):
    """Testing configuration"""

    TESTING = True

There are many ways to configure a Flask application, one of which is using Python objects. This allows me to leverage inheritance to avoid duplication (which is always good), so it's my method of choice.

It's important to understand the variables and the parameters involved in the configuration. As the documentation clearly states, FLASK_ENV and FLASK_DEBUG have to be initialised outside the application as the code might misbehave if they are changed once the engine has been started. Furthermore the FLASK_ENV variable can have only the two values development and production, and the main difference is in performances. The most important thing we need to be aware of is that if FLASK_ENV is development, then FLASK_DEBUG becomes automatically True. To sum up we have the following guidelines:

  • It's pointless to set DEBUG and ENV in the application configuration, they have to be environment variables.
  • Generally you don't need to set FLASK_DEBUG, just set FLASK_ENV to development.
  • Testing doesn't need the debug server turned on, so you can set FLASK_ENV to production during that phase. It needs TESTING set to True, though, and that has to be done inside the application.

We need now to create the application and to properly configure it. I decided to use and application factory that accepts a config_name string that is then converted into the name of the config object. For example, if config_name is development the variable config_module becomes application.config.DevelopmentConfig so that app.config.from_object can import it.

File: application/app.py

from flask import Flask


def create_app(config_name):

    app = Flask(__name__)

    config_module = f"application.config.{config_name.capitalize()}Config"

    app.config.from_object(config_module)

    @app.route("/")
    def hello_world():
        return "Hello, World!"

    return app

I also added the standard "Hello, world!" route to have a quick way to see if the server is working or not.

Last, we need something that initializes the application running the application factory and passing the correct value for the config_name parameter. The Flask development server can automatically use any file named wsgi.py in the root directory, and since WSGI is a standard specification using that makes me sure that any HTTP server we will use in production (for example Gunicorn or uWSGI) will be immediately working.

File: wsgi.py

import os

from application.app import create_app

app = create_app(os.environ["FLASK_CONFIG"])

Here, I decided to read the value of config_name from the FLASK_CONFIG variable. This is not a variable requested by the framework, but I decided to use the FLASK_ prefix anyway because it is tightly connected with the structure of the Flask application.

At this point we can happily run the Flask development server with

$ FLASK_CONFIG="development" flask run
 * Environment: production
   WARNING: This is a development server. Do not use it in a production deployment.
   Use a production WSGI server instead.
 * Debug mode: off
 * Running on http://127.0.0.1:5000/ (Press CTRL+C to quit)

Please note that it says Environment: production because we haven't configured FLASK_ENV yet. If you head to http://127.0.0.1:5000/ with your browser you can see the greetings message.

Git commit

You can see the changes made in this step through this Git commit or browse the files.

Resources

Step 3 - Application configuration

As I mentioned in the introduction, I am going to use a static JSON configuration file. The choice of JSON comes from the fact that it is a widespread file format, accessible from many programming languages, included Terraform, which I plan to use to create my production infrastructure.

File: config/development.json

[
  {
    "name": "FLASK_ENV",
    "value": "development"
  },
  {
    "name": "FLASK_CONFIG",
    "value": "development"
  }
]

I obviously need a script that extracts variables from the JSON file and converts them into environment variables, so it's time to start writing my own manage.py file. This is a pretty standard concept in the world of Python web frameworks, a tradition initiated by Django. The idea is to centralise all the management functions like starting/stopping the development server or managing database migrations. As in flask this is partially done by the flask command itself, for the time being I just need to wrap it providing suitable environment variables.

File: manage.py

#! /usr/bin/env python

import os
import json
import signal
import subprocess

import click


# Ensure an environment variable exists and has a value
def setenv(variable, default):
    os.environ[variable] = os.getenv(variable, default)


setenv("APPLICATION_CONFIG", "development")

# Read configuration from the relative JSON file
config_json_filename = os.getenv("APPLICATION_CONFIG") + ".json"
with open(os.path.join("config", config_json_filename)) as f:
    config = json.load(f)

# Convert the config into a usable Python dictionary
config = dict((i["name"], i["value"]) for i in config)

for key, value in config.items():
    setenv(key, value)


@click.group()
def cli():
    pass


@cli.command(context_settings={"ignore_unknown_options": True})
@click.argument("subcommand", nargs=-1, type=click.Path())
def flask(subcommand):
    cmdline = ["flask"] + list(subcommand)

    try:
        p = subprocess.Popen(cmdline)
        p.wait()
    except KeyboardInterrupt:
        p.send_signal(signal.SIGINT)
        p.wait()


cli.add_command(flask)

if __name__ == "__main__":
    cli()

Remember to give make the script executables with

$ chmod 775 manage.py

As you can see I'm using click, which is the recommended way to implement Flask commands. As I might use it to customise subcommands of the flask main script, I decided to stick to one tool and use it for the manage.py script as well.

The APPLICATION_CONFIG variable is the only one that I need to specify, and its default value is development. From that variable I infer the name of the JSON file with the full configuration and load environment variables from that. The flask function simply wraps the flask command provided by Flask so that I can run ./manage.py flask <subcommand> to run it using the development configuration or APPLICATION_CONFIG="foobar" ./manage.py flask <subcommand> to use the foobar one.

A clarification, to be sure you don't confuse environment variables with each other:

  • APPLICATION_CONFIG is strictly related to my project and is used only to load a JSON configuration file with the name specified in the variable itself.
  • FLASK_CONFIG is used to select the Python object that contains the configuration for the Flask application (see application/app.py and application/config.py). The value of the variable is converted into the name of a class.
  • FLASK_ENV is a variable used by Flask itself, and its values are dictated by it. See the configuration documentation mentioned in the resources of the previous section.

Now we can run the development server

$ ./manage.py flask run
 * Environment: development
 * Debug mode: on
 * Running on http://127.0.0.1:5000/ (Press CTRL+C to quit)
 * Restarting with stat
 * Debugger is active!
 * Debugger PIN: 172-719-201

Note that it now says Environment: development because of FLASK_ENV has been set to development in the configuration. As we did before, a quick visit to http://127.0.0.1:5000/ shows us that everything is up and running.

Git commit

You can see the changes made in this step through this Git commit or browse the files.

Resources:

Step 4 - Containers and orchestration

There is no better way to simplify your development than using Docker.

There is also no better way to complicate your life than using Docker.

As you might guess, I have mixed feelings about Docker. Don't get me wrong, Linux containers are an amazing concept, and Docker is very useful. It's also a complex technology that sometimes requires a lot of work to get properly configured. In this case the setup will be pretty simple, but there is a major complication with using a database server that I will describe later.

Running the application in a Docker container allows me to isolate it and to simulate the way I will run it in production. I will use docker-compose, as I expect to have other containers running in my development setup (at least the database), so I can leverage the fact that the docker-compose configuration file can interpolate environment variables. Once again through the APPLICATION_CONFIG environment variable I will select the correct JSON file, load its values in environment variables and then run the docker-compose file.

First of all we need an image for the Flask application

File: docker/Dockerfile

FROM python:3

ENV PYTHONUNBUFFERED 1

RUN mkdir /opt/code
RUN mkdir /opt/requirements
WORKDIR /opt/code

ADD requirements /opt/requirements
RUN pip install -r /opt/requirements/development.txt

As you can see the requirements directory is copied into the image, so that Docker can run the pip install command at creation time. The whole code directory will be mounted live into the image at run time.

This clearly means that every time we change the development requirements we need to rebuild the image. This is not a complicated process, so I will keep it as a manual process for now. To run the image we can create a configuration file for docker-compose.

File: docker/development.yml

version: '3.4'

services:
  web:
    build:
      context: ${PWD}
      dockerfile: docker/Dockerfile
    environment:
      FLASK_ENV: ${FLASK_ENV}
      FLASK_CONFIG: ${FLASK_CONFIG}
    command: flask run --host 0.0.0.0
    volumes:
      - ${PWD}:/opt/code
    ports:
      - "5000:5000"

As you can see, the docker-compose configuration file can read environment variables natively. To run it we first need to add docker-compose itself to the development requirements.

File: requirements/development.txt

-r testing.txt

docker-compose

Install it with pip install -r requirements/development.txt, then build the image with

$ FLASK_ENV="development" FLASK_CONFIG="development" docker-compose -f docker/development.yml build web

This will take some time, as Docker has to download all the required layers and install the requirements.

We are explicitly passing environment variables here, as we have not wrapped docker-compose in the manage script yet. Once the image has been build, we can run it with the up command

$ FLASK_ENV="development" FLASK_CONFIG="development" docker-compose -f docker/development.yml up

This command gives us the following output

Creating network "docker_default" with the default driver
Creating docker_web_1 ... done
Attaching to docker_web_1
web_1  |  * Environment: development
web_1  |  * Debug mode: on
web_1  |  * Running on http://0.0.0.0:5000/ (Press CTRL+C to quit)
web_1  |  * Restarting with stat
web_1  |  * Debugger is active!
web_1  |  * Debugger PIN: 234-361-737

You can stop the containers pressing Ctrl-C, which gracefully tears down the system. If you run the command up -d docker-compose will run as a daemon, leaving you the control of the current terminal. If docker-compose is running you can docker ps and you should see an output similar to this

CONTAINER ID  IMAGE       COMMAND                 ...   PORTS                   NAMES
c98f35635625  docker_web  "flask run --host 0.…"  ...   0.0.0.0:5000->5000/tcp  docker_web_1

If you need to explore the container you can login directly with

$ docker exec -it docker_web_1 bash

or with

$ FLASK_ENV="development" FLASK_CONFIG="development" docker-compose -f docker/development.yml exec web bash

In either case, you will end up in the /opt/code directory (which is the WORKDIR of the image), where the current directory in the host is mounted.

To tear down the containers, when running as daemon, you can run

$ FLASK_ENV="development" FLASK_CONFIG="development" docker-compose -f docker/development.yml down

Notice that the server now says Running on http://0.0.0.0:5000/, as the Docker container is using that network interface to communicate with the outside world. Since the ports are mapped, however, you can head to either http://localhost:5000 or http://0.0.0.0:5000 with your browser.

To simplify the usage of docker-compose, I want to wrap it in the manage.py script, so that it automatically receives environment variables, as their number is going to increase soon when we will add a database.

File: manage.py

#! /usr/bin/env python

import os
import json
import signal
import subprocess

import click

docker_compose_file = "docker/development.yml"
docker_compose_cmdline = ["docker-compose", "-f", docker_compose_file]


# Ensure an environment variable exists and has a value
def setenv(variable, default):
    os.environ[variable] = os.getenv(variable, default)


setenv("APPLICATION_CONFIG", "development")

# Read configuration from the relative JSON file
config_json_filename = os.getenv("APPLICATION_CONFIG") + ".json"
with open(os.path.join("config", config_json_filename)) as f:
    config = json.load(f)

# Convert the config into a usable Python dictionary
config = dict((i["name"], i["value"]) for i in config)

for key, value in config.items():
    setenv(key, value)


@click.group()
def cli():
    pass


@cli.command(context_settings={"ignore_unknown_options": True})
@click.argument("subcommand", nargs=-1, type=click.Path())
def flask(subcommand):
    cmdline = ["flask"] + list(subcommand)

    try:
        p = subprocess.Popen(cmdline)
        p.wait()
    except KeyboardInterrupt:
        p.send_signal(signal.SIGINT)
        p.wait()


@cli.command(context_settings={"ignore_unknown_options": True})
@click.argument("subcommand", nargs=-1, type=click.Path())
def compose(subcommand):
    cmdline = docker_compose_cmdline + list(subcommand)

    try:
        p = subprocess.Popen(cmdline)
        p.wait()
    except KeyboardInterrupt:
        p.send_signal(signal.SIGINT)
        p.wait()


if __name__ == "__main__":
    cli()

You might have noticed that the two functions flask and compose are basically the same code, but I resisted the temptation to refactor them because I know that the compose command will need some changes as soon as I add a database.

Now I can run ./manage.py compose up -d and ./manage.py compose down and have the environment variables automatically passed to the system.

Git commit

You can see the changes made in this step through this Git commit or browse the files.

Resources

Final words

That's enought for this first post. We started from scratch and added some boilerplate code for a Flask project, exploring what environment variables are used by the framework, then we added a configuration system, a management script, and finally we run everything in a Docker container. In the next post I will show you how to add a persistent database to the development setup and how to use an ephemeral one for the tests. If you find my posts useful please share them with whoever you thing might be interested.

Happy development!
